Fixed Pulley Diagram - Mechanical Advantage Explained #108158 (License: Personal Use)

This black-and-white line drawing depicts a fixed pulley mounted to a rigid support, with a rope passing over it; one end holds weight W, the other is pulled down with force P. The pulley changes the direction of applied force without reducing magnitude, exemplifying a 1:1 mechanical advantage. Shading and hatching emphasize the weight’s mass and structural components.

Used in educational physics content, textbooks, or STEM lesson pages explaining simple machines; targets students, teachers, and hobbyists seeking foundational mechanics knowledge.
