Picket Fence Construction Diagram - Dimensions & Assembly Guide #2172125 (License: Personal Use)

This engineering-style diagram illustrates a classic pointed-top picket fence with a total height of 75 inches (6'3"), where the fence height drops from 4' to 3-1/2'. It specifies 15 pickets (7-5/8" × 3" × 2") with varying lengths (#1-#8), 15 pointed picket caps, a 2" × 4" × 95-1/2" bottom rail with steel channel, a 2" × 4" × 95-1/2" top rail, and 4" × 4" × 75" posts with 4" × 4" × 96" post centers.

Used in fencing manufacturer catalogs, contractor manuals, or DIY project guides to communicate exact specifications for fabrication and installation; matches user intent for building or quoting a residential wood picket fence.
