NOx Emission Rate Simulation in Combustion Chambers | CFD Analysis #1821998 (License: Personal Use)

This computational fluid dynamics (CFD) visualization maps the spatial distribution of NOx formation rate inside a multi-stage combustion chamber, with labeled cross-sections (A, B) and coordinate axes (X, Y, Z). The rainbow scale indicates increasing NOx concentration from blue (low) to red (peak at 0.3765), revealing reaction zones near fuel injection points and flame stabilization regions. Geometry includes curved baffles and converging ducts influencing flow and thermal gradients.

Used in aerospace, power generation, and automotive engineering pages to illustrate emissions modeling, combustion optimization, or validation of numerical methods; targets technical audiences seeking insight into pollutant formation mechanisms.
