How to Build a Patio Cover - Step-by-Step Diagram & Plans #3011562 (License: Personal Use)

This technical illustration depicts a residential patio cover built against a house wall, featuring green vertical posts (1), teal diagonal braces (3), a purple ledger beam (4), yellow rafters, and a brown corrugated roof panel (5). The structure rests on a concrete pad and integrates with the home’s siding and stone veneer base.

Used on DIY construction guides, home improvement blogs, or woodworking plan sites to help users visualize assembly steps and component relationships before building. Matches user intent for “patio cover plans,” “how to build a carport,” or “attached pergola diagrams.”
