8-Bedroom Residential Floor Plan Layout - Symmetrical Design with Central Hall #112431 (License: Personal Use)
Search for Cliparts
About this clipart
The layout features eight identically sized bedrooms (10'-6" × 11'-3" or similar dimensions), symmetrically placed on both sides of a central double-width hallway. Two full bathrooms are positioned at the top center, flanking the hall, while multiple closets (labeled “CLG”) provide storage throughout. At the bottom, a utility or mechanical room (highlighted in red) likely houses HVAC or laundry equipment.
Used on real estate listing pages, architectural firm portfolios, or home design blogs to illustrate multi-family or large residential layouts; targets users searching for scalable housing designs, boarding homes, or group accommodations.
Related Cliparts: Detailed 8-bedroom floor plan featuring symmetrical layout, two full bathrooms, central hallway, and multiple closets. Ideal for large families or multi-generational living.
